​Polyetherimide (PEI) vs. Other Engineering Plastics: A Comparative Guide

In the world of high-performance materials, Polyetherimide (PEI) stands out for its unique combination of properties such as heat resistance, strength, and chemical stability. However, it's important to consider how it compares with other engineering plastics such as Polyetherimide (Polyetheretherketone), PPS (Polyphenylene Sulfide), and PTFE (Polytetrafluoroethylene). Each of these materials excels in specific applications, and understanding their strengths and limitations is key for selecting the right material for a given project.

1. Heat Resistance

  • Polyetherimide (PEI):
    PEI is known for its excellent heat resistance, with a glass transition temperature (Tg) of around 217°C (423°F). It can withstand continuous operating temperatures of up to 170°C (338°F), making it ideal for high-temperature applications where stability is crucial.

  • PEEK:
    PEEK is often considered the highest-performing thermoplastic in terms of heat resistance. It has a Tg of 143°C (289°F) and can maintain its mechanical properties at temperatures up to 250°C (482°F). This makes PEEK ideal for extreme environments, including aerospace and automotive industries.

  • PPS:
    PPS is another thermoplastic known for its heat resistance, with a Tg around 85°C (185°F) and a continuous service temperature of about 260°C (500°F). PPS can withstand high temperatures, though it doesn’t reach the levels of PEEK.

  • PTFE:
    PTFE is known for its exceptional heat resistance, with a melting point around 327°C (621°F). However, PTFE is primarily used in applications where its non-stick and low friction properties are the focus rather than its high-temperature mechanical properties.

2. Mechanical Strength

  • Polyetherimide (PEI):
    PEI exhibits good mechanical properties, including excellent stiffness, tensile strength, and resistance to deformation under stress. It is tough and impact-resistant, making it suitable for demanding industrial applications.

  • PEEK:
    PEEK is one of the strongest engineering thermoplastics. It provides exceptional tensile strength and resistance to creep at elevated temperatures. PEEK is highly preferred for components that experience high mechanical loads, such as in aerospace and automotive industries.

  • PPS:
    PPS offers great mechanical strength and rigidity, though its performance under high mechanical loads is not as high as PEEK. It maintains strength in high-temperature environments but is typically used in less demanding mechanical applications.

  • PTFE:
    PTFE is not known for its mechanical strength. While it offers excellent chemical resistance and low friction, its low tensile strength and high flexibility limit its use in structural applications where strength is critical.

3. Chemical Resistance

  • Polyetherimide (PEI):
    PEI has excellent resistance to a wide range of chemicals, including acids, bases, and solvents. This makes it ideal for harsh environments, although it is not as chemically resistant as PTFE.

  • PEEK:
    PEEK offers superb chemical resistance, particularly to organic solvents, acids, and bases. It outperforms many other materials in harsh chemical environments, which is why it’s commonly used in the chemical processing industry.

  • PPS:
    PPS is highly resistant to chemicals and is especially useful in environments where exposure to acids, bases, and solvents is common. It is often used in applications like pumps, valves, and other parts exposed to aggressive chemicals.

  • PTFE:
    PTFE is renowned for its exceptional chemical resistance. It is inert to nearly all chemicals and can handle a wide range of harsh substances, which makes it ideal for seals, gaskets, and other applications requiring chemical resistance.

4. Electrical Properties

  • Polyetherimide (PEI):
    PEI provides excellent electrical insulation, which makes it suitable for use in electronic and electrical applications such as connectors, circuit boards, and insulators. Its electrical properties are stable across a wide temperature range.

  • PEEK:
    PEEK also has excellent electrical insulation properties. It is often used in electronic components that require high strength and insulation in addition to heat resistance. However, PEI and PEEK are similar in electrical performance, with PEI having a slight edge in certain applications due to its broader compatibility with electrical components.

  • PPS:
    PPS offers good electrical insulation properties, but it is less commonly used in high-precision electrical applications compared to PEI or PEEK. Its resistance to electrical breakdown is adequate but not exceptional.

  • PTFE:
    PTFE is an excellent electrical insulator and is widely used in applications requiring dielectric properties. It is highly favored for wires, cables, and insulating films due to its low dielectric constant and high insulation resistance.

5. Cost-Effectiveness

  • Polyetherimide (PEI):
    PEI is more affordable than PEEK, but it is still a premium material compared to many other thermoplastics. It provides a good balance of cost and performance, making it a popular choice for many industrial applications without the high cost of PEEK.

  • PEEK:
    PEEK is the most expensive among these materials. Its high-performance properties, especially at extreme temperatures, justify the cost in critical applications where performance outweighs the price.

  • PPS:
    PPS is generally less expensive than both PEI and PEEK, offering a good balance between cost and performance. Its ability to resist high temperatures and chemicals makes it a more affordable option for many industrial applications.

  • PTFE:
    PTFE is generally less expensive than PEEK but can be costlier than PEI, especially in large quantities. However, its chemical resistance and unique properties, like non-stick characteristics, make it worth the investment for specific applications.

6. Applications

  • Polyetherimide (PEI):
    PEI is used in aerospace, automotive, electronics, and medical devices due to its heat resistance, mechanical strength, and electrical properties. It is commonly found in electrical connectors, housings, and internal components of high-performance machines.

  • PEEK:
    PEEK is used in extremely demanding environments such as aerospace, automotive, chemical processing, and medical devices. It is commonly found in high-performance seals, bearings, and structural components.

  • PPS:
    PPS is used in automotive, electrical, and industrial applications, particularly where high chemical resistance and moderate heat resistance are needed. It is frequently used for components like pumps, valves, and bearings.

  • PTFE:
    PTFE is primarily used in chemical processing, food processing, and electrical insulation. Its non-stick properties make it ideal for use in gaskets, seals, and lubricants.


Each of these engineering plastics—PEI, PEEK, PPS, and PTFE—offers a unique set of properties that makes them suitable for specific applications. PEI provides an excellent balance between performance and cost, while PEEK excels in extreme environments requiring the highest performance. PPS offers good chemical resistance and heat stability at a more affordable price point, and PTFE remains the go-to material for chemical resistance and non-stick applications.
